UL3132 is a silicone wire with a rated voltage of 300V and a rated temperature of 150℃. The conductor is tinned copper, with specifications ranging from 30AWG to 16AWG. It has the characteristics of low resistance, strong conductivity, and salt spray corrosion resistance, and is suitable for household appliances, lighting fixtures, and other fields.
Feature
Condutor:Strands Tinned/Bare Copper
Insulation:Silicone rubber
Reted Temperature:150℃
Reted Voltage:300Vac
Inodorous Atoxic
Good elasticity and softness
Has the very high resistivity
Good heat resistance
Use the high temperature vulcanization process
Passes UL & CSA FT2 horizontal flame test
Reference standard：UL758,UL1581
Environmental testing pass ROHS
UL 30awg to 16awg
Structure
Standard Colors:Multiple colors to choose
Our Service
Corporate vision
Become a world-renowned supplier of electronic components, providing customers with satisfactory electronic solutions.
Social responsibility
Make our users products safer. Save resources and make the planet we live in a better and more harmonious place.
Quality policy
Quality first, delivery guarantee, active service, customer first, step by step, zero defect management.
3F concern
High temperature resistance, high pressure resistance, ultra-thin, environmental protection.
If you have any questions, you can consult us and we will reply to you immediately!
Or if you haven't found the model you need, you can contact us directly.
You can contact us through the floating window on the right and the button below.
Partners
Solution
One-Stop Shopping
FAQ
Q:1.When can I get a quote?
A:We usually quote within 24 hours after we get your inquiry.
Q:2.What is your terms of delivery?
A:We accept EXW, FOB, CFR, CIF. You can choose the one which is the most convenient or cost effective for you.
Technical Parameters
|
STYLE
|
standard AWG
|
Conductor size (No./ mm) ±0.005mm
|
Conductor resistance 20℃ (Ω/Km)
|
Conductor Dia. (mm)
|
insulation thickness (mm) |
Overall diameter (mm) |
||
|
Nom. |
Min. |
Nom. |
Tole. |
|||||
|
|
16 |
7/0.49 |
14.60 |
1.50 |
0.40 |
0.33 |
2.30 |
±0.10 |
| 18 |
7/0.39 |
23.20 |
1.19 |
0.40 |
0.33 |
1.97 |
±0.10 |
|
|
30/0.18 |
23.20 |
1.14 |
0.40 |
0.33 |
1.94 |
±0.10 |
||
|
41/0.16 |
23.20 |
1.18 |
0.40 |
0.33 |
1.97 |
±0.10 |
||
| 20 |
1/0.813 |
36.70 |
0.813 |
0.46 |
0.33 |
1.73 |
±0.10 |
|
|
7/0.30 |
36.70 |
0.92 |
0.46 |
0.33 |
1.85 |
±0.10 |
||
|
19/0.19 |
36.70 |
0.95 |
0.46 |
0.33 |
1.87 |
±0.10 |
||
| 22 |
12/0.18 |
59.40 |
0.72 |
0.46 |
0.33 |
1.64 |
±0.10 |
|
|
17/0.16 |
59.40 |
0.76 |
0.46 |
0.33 |
1.70 |
±0.10 |
||
|
7/0.254 |
59.40 |
0.76 |
0.46 |
0.33 |
1.70 |
±0.10 |
||
|
1/0.65 |
56.40 |
0.65 |
0.46 |
0.33 |
1.57 |
±0.10 |
||
| 24 |
133/0.05 |
94.20 |
0.67 |
0.40 |
0.33 |
1.47 |
±0.10 |
|
|
19/0.12 |
94.20 |
0.60 |
0.40 |
0.33 |
1.40 |
±0.10 |
||
|
11/0.16 |
94.20 |
0.61 |
0.40 |
0.33 |
1.41 |
±0.10 |
||
|
7/0.20 |
94.20 |
0.61 |
0.40 |
0.33 |
1.41 |
±0.10 |
||
|
1/0.51 |
89.30 |
0.51 |
0.40 |
0.33 |
1.31 |
±0.10 |
||
| 26 |
19/0.1 |
150.00 |
0.51 |
0.40 |
0.33 |
1.31 |
±0.10 |
|
|
7/0.16 |
150.00 |
0.48 |
0.40 |
0.33 |
1.28 |
±0.10 |
||
|
1/0.4 |
143.00 |
0.40 |
0.40 |
0.33 |
1.20 |
±0.10 |
||
|
28 |
7/0.127 |
239.00 |
0.38 |
0.40 |
0.33 |
1.18 |
±0.10 |
|
|
30 |
7/0.10 |
381.00 |
0.30 |
0.40 |
0.33 |
1.10 |
±0.10 |
|
