As a member of the UL electronic wire series, UL1569 is commonly used inside various devices. It uses 30-2AWG single or stranded bare copper and tin plated copper wire as conductors, combined with PVC insulation layer, and has characteristics such as acid and alkali resistance, moisture resistance, and mold resistance. The rated voltage is 300V and the working temperature can reach 105 ℃. It is widely used for connecting internal power and signal devices in electronic equipment and electrical appliances.
Feature
Condutor :stranded or solid,tinned or bare
Insulation :PVC
Reted Temperature:105℃
Reted Voltage:600Vac
Uniform thickness of wire to ensure easy stripping and cutting
Good flame retardancy
Low temperature soft good performance
Using the hot extrusion processing
Can be twisted pair and multi-core
Resistant to acids,alkalies,oils,moisture and fungus
Combustion Test:Passes UL vw-1 flame test
Standard Reference:UL 758,UL1581
Environmental testing pass ROHS
UL 30awg to 10awg
Application
UL1569 wires are widely used in the field of electronic devices. Inside the computer host, it is responsible for connecting components such as the motherboard, hard drive, and optical drive, ensuring stable power transmission and signal communication between each component. With good insulation performance, it can effectively avoid electromagnetic interference between lines and ensure stable operation of the computer. In the manufacturing of smartphones, UL1569 wires are used to connect the phone motherboard with the screen, battery, etc. Their soft and bendable characteristics meet the compact space and complex wiring requirements inside the phone, and can maintain stable performance in different temperature environments, ensuring the normal use of the phone. In terms of household appliances, such as smart TVs and air conditioners, it is often used for internal circuit connections to provide reliable operation for the appliances.
Structure
Standard Colors: black, white, red, yellow, green, blue, brown, grey, orange, violet
Package Type：500Ft/roll, 1000Ft/roll. 2000Ft/roll
We accept EXW, FOB, CFR, CIF.
You can choose the one which is the most convenient or cost effective for you.
Certification
CCC
SA
UL
VDE
IECQ
Solution
FAQ
Q:1.Is UL1569 wire flame-resistant?
A:Yes, UL1569 wire can pass UL VW - 1 and CSA FT1 vertical flammability tests. This flame - resistant property enhances the safety of electrical systems where it is used, reducing the risk of fire caused by electrical failures.
Q:2.What is the insulation material of UL1569 wire and what are its advantages?
A:The insulation material of UL1569 wire is PVC. PVC insulation has advantages such as uniform thickness for easy stripping and cutting, good electrical insulation performance, and resistance to acids, alkalis, moisture, and mold, which can protect the conductor and ensure the stability of the wire's performance.
|
STYLE
|
SIZE AWG
|
Conductor construction (No./ mm) ±0.005
|
Conductor resistance 20℃(Ω/Km)
|
Conductor diameter (mm)
|
insulation thickness (mm) Nom./Min.
|
Over diameter (mm) |
||
|
Nom. |
Tole. |
|||||||
|
1569
|
2 |
7/95/0.254 |
0.555 |
8.58 |
0.80 |
0.69 |
10.20 |
±0.20 |
|
3 |
7/76/0.254 |
0.700 |
7.67 |
0.80 |
0.69 |
9.27 |
±0.20 |
|
|
4 |
7/60/0.254 |
0.882 |
6.82 |
0.80 |
0.69 |
8.42 |
±0.15 |
|
|
5 |
7/46/0.254 |
1.113 |
5.97 |
0.80 |
0.69 |
7.57 |
±0.15 |
|
|
6 |
7/38/0.254 |
1.403 |
5.41 |
0.80 |
0.69 |
7.00 |
±0.15 |
|
|
7 |
7/30/0.254 |
1.768 |
4.82 |
0.80 |
0.69 |
6.42 |
±0.15 |
|
|
8 |
168/0.254 |
2.230 |
3.80 |
0.80 |
0.69 |
5.40 |
±0.15 |
|
|
10 |
105/0.254 |
3.54 |
3.00 |
0.50 |
0.45 |
4.00 |
±0.15 |
|
|
12 |
65/0.254 |
5.64 |
2.36 |
0.50 |
0.45 |
3.36 |
±0.15 |
|
|
14 |
19/0.374 |
8.96 |
1.88 |
0.50 |
0.45 |
2.90 |
±0.15 |
|
|
14 |
41/0.254 |
8.96 |
1.88 |
0.50 |
0.45 |
2.90 |
±0.15 |
|
|
16 |
26/0.254 |
14.60 |
1.50 |
0.40 |
0.33 |
2.30 |
±0.1 |
|
|
18 |
7/0.39 |
23.20 |
1.19 |
0.40 |
0.33 |
1.95 |
±0.1 |
|
|
18 |
41/0.16 |
23.20 |
1.18 |
0.40 |
0.33 |
1.95 |
±0.1 |
|
|
18 |
16/0.254 |
23.20 |
1.17 |
0.40 |
0.33 |
1.95 |
±0.1 |
|
|
18 |
19/0.235 |
23.20 |
1.17 |
0.40 |
0.33 |
1.95 |
±0.1 |
|
|
18 |
1/1.02 |
23.20 |
1.02 |
0.40 |
0.33 |
1.85 |
±0.1 |
|
|
20 |
10/0.254 |
36.70 |
0.92 |
0.40 |
0.33 |
1.75 |
±0.1 |
|
|
20 |
19/0.19 |
36.70 |
0.95 |
0.40 |
0.33 |
1.75 |
±0.1 |
|
|
20 |
21/0.18 |
36.70 |
0.95 |
0.40 |
0.33 |
1.75 |
±0.1 |
|
|
22 |
7/0.254 |
59.40 |
0.77 |
0.40 |
0.33 |
1.56 |
±0.1 |
|
|
22 |
19/0.15 |
59.40 |
0.75 |
0.40 |
0.33 |
1.55 |
±0.1 |
|
|
22 |
17/0.16 |
59.40 |
0.76 |
0.40 |
0.33 |
1.56 |
±0.1 |
|
|
24 |
11/0.16 |
94.20 |
0.61 |
0.40 |
0.33 |
1.41 |
±0.1 |
|
|
24 |
7/0.20 |
94.20 |
0.61 |
0.40 |
0.33 |
1.41 |
±0.1 |
|
|
24 |
19/0.12 |
94.20 |
0.60 |
0.40 |
0.33 |
1.40 |
±0.1 |
|
|
26 |
7/0.16 |
150.00 |
0.48 |
0.40 |
0.33 |
1.28 |
±0.1 |
|
|
28 |
7/0.127 |
239.00 |
0.38 |
0.40 |
0.33 |
1.18 |
±0.1 |
|
|
30 |
7/0.10 |
381.00 |
0.31 |
0.40 |
0.33 |
1.11 |
±0.1 |
|
