MIL-DTL-16878-C is a US military standard wire. The rated voltage can reach 600V, with good electrical insulation performance and temperature resistance, suitable for internal wiring of electronic devices.

Feature

MIL-DTL-16878-C

Condutor:Strands silver Copper

Insulation:Silver Copper

Reted Temperature:200℃

Reted Voltage:600Vac

Good elasticity and softness

Use the high temperature vulcanization process

Good adsorption ability

Standard Reference：MIL-DTL-16878/7C

Environmental testing pass ROHS

24awg to 10awg

Application

General military standard internal wiring wires

The signal transmission harness for aircraft engine sensors and internal interconnection of flight control systems can withstand temperature fluctuations and mechanical vibrations in the cabin. This wire is also commonly used for low-voltage circuit connections in satellite equipment.

In the aerospace field

The internal wiring of missile guidance systems, the interconnection of tank communication and fire control systems, and the anti-corrosion properties of tinned copper wire conductors and the protective performance of PVC insulation can cope with complex battlefield conditions.

In the field of military equipment

The wiring in the explosion-proof area of the oil drilling platform and the internal connection of high-precision medical imaging equipment will also use this wire, which meets the strict operational requirements with its flame retardant and stable electrical performance.

In industrial high reliability scenarios

Structure

MIL-DTL-16878-C

Standard Colors:Multiple Kinds

MIL-DTL-16878-C

Partners

Certification

IECQ

VDE

CCC

Solution

FAQ

Q:1.What is your terms of delivery?

A:We accept EXW, FOB, CFR, CIF. You can choose the one which is the most convenient or cost effective for you.

Q:2.When can I get a quote?

A:We usually quote within 24 hours after we get your inquiry.

Q:3.Are you a manufacturer?

A: We are a manufacturer located in Shenzhen, Guangdong, China. Our company's sales and service network covers the whole world to guarantee the professionalism of products and the satisfaction of customers' after-sales service.

Technical Parameters

STYLE	standard AWG	Conductor size (No./ mm) ±0.005mm	Conductor Dia. (mm)	insulation thickness (mm)	Overall diameter (mm)
STYLE	standard AWG	Conductor size (No./ mm) ±0.005mm	Conductor Dia. (mm)	insulation thickness (mm)	Max	Min
M16878/7BEB*	24	7/0.203	0.610	0.40	1.473	1.321
M16878/7BFB*	22	7/0.254	0.762	0.40	1.626	1.473
M16878/7BGB*	20	7/0.320	0.965	0.40	1.829	1.676
M16878/7BGC*	20	10/0.254	0.965	0.40	1.829	1.676
M16878/7BHB*	18	7/0.404	1.219	0.40	2.083	1.930
M16878/7BHD*	18	16/0.254	1.219	0.40	2.083	1.930
M16878/7BJE*	16	19/0.287	1.448	0.40	2.311	2.159
M16878/7BJF*	16	26/0.254	1.448	0.40	2.311	2.159
M16878/7BKE*	14	19/0.361	1.829	0.60	3.099	2.946
M16878/7BKH*	14	41/0.254	1.829	0.60	3.099	2.946
M16878/7BLE*	12	19/0.455	2.311	0.60	3.581	3.429
M16878/7BLJ*	12	65/0.254	2.311	0.60	3.581	3.429
M16878/7BMK*	10	105/0.254	2.819	0.60	4.216	3.962
