UL3135 is a silicone rubber insulated wire. Rated temperature 200℃, rated voltage 600V AC. The conductor is a single or twisted tin plated or bare copper wire with uniform insulation thickness, easy to peel and cut. Compliant with RoHS standards, commonly used for internal connections in electronic and electrical equipment.
Feature
Condutor:Strands Tinned/Bare Copper
Insulation:Silicone rubber
Reted Temperature:200℃
Reted Voltage:600Vac
Good heat resistance
Inodorous Atoxic
Good elasticity and softness
Use the high temperature vulcanization process
Passes UL & CSA FT2 horizontal flame test
Reference standard：UL758,UL1581
Environmental testing pass ROHS
UL 26awg to 12awg
Application
UL3135 wires are widely used.
In the field of home appliances
It can be used for internal wiring of microwave ovens, ovens, and other high-temperature components such as heating elements, and can work stably at a high temperature of 200℃.
In the field of lighting
It can be used as an internal connecting wire for lighting fixtures, and its good insulation performance ensures electrical safety. Its flexible characteristics facilitate complex wiring inside the lighting fixtures.
In the industrial field
Suitable for industrial robots, CNC machine tools and other equipment. Can be used as a servo cable, capable of withstanding high-frequency bending motion, ensuring stable transmission of signals and power. It can also be used for photovoltaic power plants, connecting inverters and other components.
In fields such as aerospace, automobiles, and ships that require high performance of electrical wires
UL3135 can also play a role, providing reliable connections for related electrical systems with its high and low temperature resistance, corrosion resistance, and other characteristics.
Structure
Colors Available: BLACK, WHITE, RED, YELLOW, GREEN, BLUE, BROWN, GREY, ORANGE, VIOLET
Package Type：500Ft/roll, 1000Ft/roll, 2000Ft/roll.
Our Factory
About 3F
Partners
Solution
FAQ
Q:1.What is the delivery time for mass production?
A:About 20 to 30 days.
Q:2.When can I get a quote?
A:We usually quote within 24 hours after we get your inquiry.
Technical Parameters
|
STYLE
|
standard AWG
|
Conductor size (No./ mm) ±0.005mm
|
Conductor resistance 20℃ (Ω/Km)
|
Conductor Dia. (mm)
|
insulation thickness (mm) |
Overall diameter (mm) |
||
|
Nom. |
Min. |
Nom. |
Tole. |
|||||
|
3135 |
12 |
65/0.254 |
5.64 |
2.36 |
0.80 |
0.69 |
3.95 |
±0.15 |
| 13 |
52/0.254 |
7.10 |
2.12 |
0.80 |
0.69 |
3.68 |
±0.15 |
|
|
37/0.3 |
7.10 |
2.11 |
0.80 |
0.69 |
3.67 |
±0.15 |
||
| 14 |
41/0.254 |
8.96 |
1.90 |
0.80 |
0.69 |
3.46 |
±0.15 |
|
|
1/1.63 |
8.78 |
1.63 |
0.80 |
0.69 |
3.20 |
±0.15 |
||
|
7/0.616 |
8.96 |
1.90 |
0.80 |
0.69 |
3.46 |
±0.15 |
||
|
7/60/0.08 |
8.96 |
2.15 |
0.80 |
0.69 |
3.71 |
±0.15 |
||
| 16 |
7/0.49 |
14.60 |
1.50 |
0.80 |
0.69 |
3.06 |
±0.15 |
|
|
26/0.254 |
14.60 |
1.50 |
0.80 |
0.69 |
3.06 |
±0.15 |
||
|
50/0.18 |
14.60 |
1.50 |
0.80 |
0.69 |
3.06 |
±0.15 |
||
|
54/0.18 |
14.60 |
1.52 |
0.80 |
0.69 |
3.08 |
±0.15 |
||
|
1/1.29 |
14.60 |
1.29 |
0.80 |
0.69 |
2.85 |
±0.15 |
||
| 18 |
1/1.02 |
23.20 |
1.02 |
0.80 |
0.69 |
2.60 |
±0.15 |
|
|
41/0.16 |
23.20 |
1.18 |
0.80 |
0.69 |
2.74 |
±0.15 |
||
|
7/0.39 |
23.20 |
1.19 |
0.80 |
0.69 |
2.75 |
±0.15 |
||
|
30/0.18 |
23.20 |
1.19 |
0.80 |
0.69 |
2.75 |
±0.15 |
||
|
34/0.18 |
23.20 |
1.21 |
0.80 |
0.69 |
2.77 |
±0.15 |
||
|
16/0.254 |
23.20 |
1.17 |
0.80 |
0.69 |
2.75 |
±0.15 |
||
| 20 |
7/0.30 |
36.70 |
0.92 |
0.80 |
0.69 |
2.48 |
±0.10 |
|
|
1/0.813 |
35.20 |
0.813 |
0.80 |
0.69 |
2.37 |
±0.10 |
||
|
21/0.18 |
36.70 |
0.95 |
0.80 |
0.69 |
2.51 |
±0.10 |
||
| 22 |
7/0.254 |
59.40 |
0.76 |
0.80 |
0.69 |
2.32 |
±0.10 |
|
|
1/0.65 |
56.40 |
0.65 |
0.80 |
0.69 |
2.21 |
±0.10 |
||
| 24 |
11/0.16 |
94.20 |
0.61 |
0.80 |
0.69 |
2.15 |
±0.10 |
|
|
7/0.20 |
94.20 |
0.61 |
0.80 |
0.69 |
2.15 |
±0.10 |
||
|
26 |
7/0.16 |
150.00 |
0.48 |
0.80 |
0.69 |
2.05 |
±0.10 |
|
