UL3423 XLPE Connection Wire is a UL certified single core insulated electronic wire with a rated voltage of 300V and a long-term operating temperature of 125℃. It uses multi stranded copper conductors, which are flexible and easy to process. UL3423 XLPE Connection Wire has excellent heat resistance, flame retardancy, aging resistance, and electrical performance, meets UL safety standards, and is widely used for internal wiring of industrial control, home appliances, power supplies, and new energy equipment. It is a commonly used internal connection wire for exporting equipment to North America.
Feature
Condutor :Strands Tinned/Bare Copper
Insulation :XLPE
Reted Temperature:125℃
Reted Voltage:300Vac
Can be twisted pair and multi-core
Low smoke
Chemistry stability is good
Non-halogen
Standard Reference:UL758,UL1581
Environmental testing pass ROHS/REACH
UL 30awg to 16awg
Application
UL3423 XLPE Connection Wire is a UL certified single core (XLPE) insulated electronic wire with a rated voltage of 300V and a temperature resistance of 125℃. It has the characteristics of heat resistance, flame retardancy, and chemical corrosion resistance, and is suitable for internal wiring in multiple scenarios. In the industrial field, it is used for internal power and signal connections in PLC control cabinets, servo drives, and frequency converters. It is also suitable for internal wiring in new energy vehicle charging stations, onboard controllers, and battery management systems (BMS), meeting the requirements of high temperature and vibration environments. In the field of home appliances, UL3423 XLPE Connection Wire is suitable for internal circuit connections such as air conditioners, refrigerators, washing machines, and microwave ovens to ensure long-term stable operation. In the field of electronic devices, UL3423 XLPE Connection Wire is used for internal wiring of servers, power adapters, LED driver power supplies, and instruments. It can also be used for compliant internal wiring of equipment exported to North America, in compliance with UL safety and environmental requirements.
Structure
Colors Available: BLACK, WHITE, RED, YELLOW, GREEN, BLUE, BROWN, GREY, ORANGE, VIOLET
Our Factory
Established in 1993, 3F Electronics Industry Corp is a professional manufacturer and exporter that is concerned with the design, development and production of wires and tubes. We are located in Shenzhen, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
Solution
Partners
FAQ
Q:1.When can I get a quote?
A:We usually quote within 24 hours after we get your inquiry.
Q:2.Are you a manufacturer?
A: We are a manufacturer located in Shenzhen, Guangdong, China. Our company's sales and service network covers the whole world to guarantee the professionalism of products and the satisfaction of customers' after-sales service.
Technical Parameters
|
STYLE |
Standard AWG |
Conductor size (No./ mm) ±0.005mm |
Conductor resistance 20℃ (Ω/Km) |
Conductor Dia.(mm) |
insulation thickness (mm) |
Overall diameter (mm) |
||
|
Nom. |
Min. |
Nom. |
Tole. |
|||||
|
3423 |
16 |
26/0.254 |
14.60 |
1.50 |
0.40 |
0.33 |
2.30 |
±0.10 |
|
18 |
16/0.254 |
23.20 |
1.17 |
0.40 |
0.33 |
1.95 |
±0.10 |
|
|
20 |
21/0.18 |
36.70 |
0.95 |
0.40 |
0.33 |
1.75 |
±0.10 |
|
|
22 |
17/0.16 |
59.40 |
0.76 |
0.40 |
0.33 |
1.56 |
±0.10 |
|
|
24 |
11/0.16 |
94.20 |
0.61 |
0.40 |
0.33 |
1.41 |
±0.10 |
|
|
26 |
7/0.16 |
150.00 |
0.48 |
0.40 |
0.33 |
1.28 |
±0.10 |
|
|
28 |
7/0.127 |
239.00 |
0.38 |
0.40 |
0.33 |
1.18 |
±0.10 |
|
|
30 |
7/0.10 |
381.00 |
0.30 |
0.40 |
0.33 |
1.10 |
±0.10 |
|
